About CityView Sliding Stacking Patio Door

The CityView Sliding Stacking Patio door was designed to suit modern architectural requirements. This door provides the ability to achieve expansive openings without compromising on performance.
Opening up to two thirds of their widths and slowing indoor living areas to be connected to patios, sundecks and courtyards.

The fly door and security door tracks are already incorporated into the framing design, meaning no addition tracks are required for screening. The Cityview sliding stacking patio door also offers a range of roller options to accommodate heavy panel weights.

Designed and engineered in Australia, this sliding stacking patio door has been tested to and meets Australian Standard AUS2047.

Design Features:

Accepts glass thickness from 6mm-20mm
Compatible with other Darley Aluminium Commercial and Residential Systems
Range of sub head and sub sill options.
Range of heavy-duty mullion options for tall framing and high wind areas
Unique “Slide-in” Jamb and “Snap-in” Jamb Receivers design results in minimal tooling required
Door panels slide internally

Maximum panel size 2700 mm high x 1350 mm wide subject to complying with the appropriate glazing standard and design wind load requirements
Multiple screening options available for external screening
Range of roller options to accommodate heavy panel weights
Pre-punched Sill requires no fabrication
Tested and approved by an independent NATA accredited laboratory
NFRC Energy rated

Tested to AS2047

Under the Building Code of Australia, we are required to produce windows and doors that meet mandatory minimum specifications under Australian Standard (AS) 2047 – including AS1288.

Simulations of High Winds and Driving Rains

AS4420.2 Deflection Test – positive and negative wind pressures are applied to the face of the window to test the maximum deflection under wind load.
AS4420.5 Water Penetration Resistance Test – to verify that no water leaks through the window into the building.

Operating Force Requirement

AS4420.3 Operating Force Test – to verify that an opening sash is capable of opening and closing without undue effort.

Air Infiltration Pressure

AS4220.4 Air In filtration Test – the air leakage of a window is tested to ensure energy and acoustic efficiency.

Ultimate Strength Testing

AS4420.6 Ultimate Strength Test – negative and positive wind pressures are applied to the window to at least 1.5 times the design wind pressure to ensure it does not fail in unusual wind conditions.

CityView Cutting Sheets

Download CAD Drawings

Please note: file will be in .zip format.

About

About CityView Sliding Stacking Patio Door

The CityView Sliding Stacking Patio door was designed to suit modern architectural requirements. This door provides the ability to achieve expansive openings without compromising on performance.
Opening up to two thirds of their widths and slowing indoor living areas to be connected to patios, sundecks and courtyards.

The fly door and security door tracks are already incorporated into the framing design, meaning no addition tracks are required for screening. The Cityview sliding stacking patio door also offers a range of roller options to accommodate heavy panel weights.

Designed and engineered in Australia, this sliding stacking patio door has been tested to and meets Australian Standard AUS2047.

Design Features:

Accepts glass thickness from 6mm-20mm
Compatible with other Darley Aluminium Commercial and Residential Systems
Range of sub head and sub sill options.
Range of heavy-duty mullion options for tall framing and high wind areas
Unique “Slide-in” Jamb and “Snap-in” Jamb Receivers design results in minimal tooling required
Door panels slide internally

Maximum panel size 2700 mm high x 1350 mm wide subject to complying with the appropriate glazing standard and design wind load requirements
Multiple screening options available for external screening
Range of roller options to accommodate heavy panel weights
Pre-punched Sill requires no fabrication
Tested and approved by an independent NATA accredited laboratory
NFRC Energy rated

Wers Ratings

Testing

Tested to AS2047

Under the Building Code of Australia, we are required to produce windows and doors that meet mandatory minimum specifications under Australian Standard (AS) 2047 – including AS1288.

Simulations of High Winds and Driving Rains

AS4420.2 Deflection Test – positive and negative wind pressures are applied to the face of the window to test the maximum deflection under wind load.
AS4420.5 Water Penetration Resistance Test – to verify that no water leaks through the window into the building.

Operating Force Requirement

AS4420.3 Operating Force Test – to verify that an opening sash is capable of opening and closing without undue effort.

Air Infiltration Pressure

AS4220.4 Air In filtration Test – the air leakage of a window is tested to ensure energy and acoustic efficiency.

Ultimate Strength Testing

AS4420.6 Ultimate Strength Test – negative and positive wind pressures are applied to the window to at least 1.5 times the design wind pressure to ensure it does not fail in unusual wind conditions.

Technical Manuals

Cutting Sheet

CityView Cutting Sheets

CAD Drawings

Download CAD Drawings

Please note: file will be in .zip format.

Download the CityView™ Catalogue

Specifications

System	Maximum weight per panel	Maximum hieight	Maxiumim Width	Glass Thickness	Test Report No.	Water Rating (Pa)	Structural (Pa)	Ultimate (Pa)
Standard Interlock Patio Slider	120kg	2750mm	1350mm	6mm – 20mm	AZT0116.10	300	1,200	2,326
Single Piece Interlock Patio Slider	120kg	2750mm	1350mm	6mm – 20mm	AZT0189.18	250	1,100	2,000
Standard Interlock Patio Stacker	120kg	2750mm	1350mm	6mm – 20mm	AZT2586.12	200	1,200	2,326
Single Piece Interlock Patio Stacker	120kg	2750mm	1350mm	6mm – 20mm	AZT0190.18	250	1,100	2,000

image presents sliding stacking patio door

Commercial Hardware

Find Out More

Window ID	System	Glazing	Cooling Stars	Heating Stars	Cool %	Heat %	Uw	SHGC	Tvw	Air Inf
DAR-020-01	“Cityview” Patio Sliding Door - Single Glazed	6.38CPNtl	3	3.5	50%	29%	4.4	0.4	0.46	0.48
DAR-020-02	“Cityview” Patio Sliding Door - Single Glazed	6.38CPGn	3.5	3.5	51%	29%	4.3	0.4	0.55	0.48
DAR-020-03	“Cityview” Patio Sliding Door - Single Glazed	6.38CPGy	3.5	3	51%	28%	4.3	0.39	0.3	0.48
DAR-020-04	“Cityview” Patio Sliding Door - Single Glazed	6TS21	4	2	56%	7%	5.4	0.24	0.16	0.48
DAR-020-05	“Cityview” Patio Sliding Door - Single Glazed	6Gy	2.5	2	38%	10%	6.1	0.45	0.32	0.48
DAR-020-06	“Cityview” Patio Sliding Door - Single Glazed	6Clr	1	2.5	22%	19%	6.1	0.65	0.68	0.48
DAR-020-07	“Cityview” Patio Sliding Door - Single Glazed	6EVGy	3.5	3	55%	23%	4.5	0.32	0.25	0.48
DAR-020-08	“Cityview” Patio Sliding Door - Single Glazed	6SolEGy	4	3	58%	21%	4.4	0.28	0.23	0.48
DAR-020-09	“Cityview” Patio Sliding Door - Single Glazed	6SolEClr	3	3.5	49%	29%	4.4	0.41	0.46	0.48
DAR-020-10	“Cityview” Patio Sliding Door - Single Glazed	6.38CPClr	2.5	4	40%	36%	4.3	0.54	0.63	0.48
DAR-020-11	“Cityview” Patio Sliding Door - Single Glazed	6EVClr	2.5	3.5	43%	32%	4.5	0.49	0.51	0.48
DAR-020-12	“Cityview” Patio Sliding Door - Single Glazed	10.38GyLam	2.5	2	39%	13%	5.9	0.46	0.33	0.48
DAR-020-13	“Cityview” Patio Sliding Door - Single Glazed	10.38CPClr	2.5	3.5	43%	35%	4.3	0.51	0.61	0.48
DAR-020-14	“Cityview” Patio Sliding Door - Single Glazed	10.38CPGy	3.5	3	52%	28%	4.3	0.37	0.29	0.48
DAR-020-15	“Cityview” Patio Sliding Door - Single Glazed	10.38CPNtl	3.5	3.5	51%	29%	4.3	0.4	0.48	0.48
DAR-020-16	“Cityview” Patio Sliding Door - Single Glazed	6EVBGn	3.5	3	52%	24%	4.6	0.36	0.44	0.48
DAR-020-17	“Cityview” Patio Sliding Door - Single Glazed	10.38CPGn	3.5	3	54%	26%	4.3	0.35	0.5	0.48
DAR-020-18	“Cityview” Patio Sliding Door - Single Glazed	6AzTS21	4	1.5	57%	6%	5.4	0.23	0.12	0.48
DAR-020-19	“Cityview” Patio Sliding Door - Single Glazed	6EVAB	4	2.5	57%	20%	4.6	0.29	0.3	0.48
DAR-020-20	“Cityview” Patio Sliding Door - Single Glazed	6EVSpGn	4	2.5	56%	20%	4.6	0.3	0.38	0.48
DAR-021-01	“Cityview” Patio Stacking Door - Single Glazed	6.38CPNtl	3	3	47%	24%	4.8	0.41	0.46	1.23
DAR-021-02	“Cityview” Patio Stacking Door - Single Glazed	6.38CPGn	3	3	48%	24%	4.7	0.41	0.56	1.23
DAR-021-03	“Cityview” Patio Stacking Door - Single Glazed	6.38CPGy	3	3	48%	23%	4.7	0.4	0.31	1.23
DAR-021-04	“Cityview” Patio Stacking Door - Single Glazed	6TS21	3.5	1.5	54%	1%	5.7	0.25	0.16	1.23
DAR-021-05	“Cityview” Patio Stacking Door - Single Glazed	6Gy	2	1.5	36%	4%	6.4	0.46	0.33	1.23
DAR-021-06	“Cityview” Patio Stacking Door - Single Glazed	6Clr	1	2	19%	14%	6.4	0.66	0.7	1.23
DAR-021-07	“Cityview” Patio Stacking Door - Single Glazed	6EVGy	3.5	2.5	52%	18%	4.9	0.33	0.25	1.23
DAR-021-08	“Cityview” Patio Stacking Door - Single Glazed	6SolEGy	3.5	2.5	55%	16%	4.8	0.29	0.24	1.23
DAR-021-09	“Cityview” Patio Stacking Door - Single Glazed	6SolEClr	3	3	47%	24%	4.8	0.42	0.47	1.23
DAR-021-10	“Cityview” Patio Stacking Door - Single Glazed	6.38CPClr	2	3.5	38%	31%	4.7	0.55	0.65	1.23
DAR-021-11	“Cityview” Patio Stacking Door - Single Glazed	6EVClr	2.5	3	41%	27%	4.9	0.5	0.53	1.23
DAR-021-12	“Cityview” Patio Stacking Door - Single Glazed	10.38GyLam	2	2	36%	8%	6.2	0.47	0.33	1.23
DAR-021-13	“Cityview” Patio Stacking Door - Single Glazed	10.38CPNtl	3	3	50%	27%	4.5	0.4	0.49	1.23
DAR-021-14	“Cityview” Patio Stacking Door - Single Glazed	10.38CPGy	3.5	3	51%	26%	4.5	0.38	0.3	1.23
DAR-021-15	“Cityview” Patio Stacking Door - Single Glazed	10.38CPClr	2.5	3.5	42%	33%	4.5	0.51	0.63	1.23
DAR-021-16	“Cityview” Patio Stacking Door - Single Glazed	10.38CPGn	3.5	3	53%	24%	4.5	0.35	0.51	1.23
DAR-021-17	“Cityview” Patio Stacking Door - Single Glazed	6AzTS21	4	1.5	56%	3%	5.5	0.23	0.12	1.23
DAR-021-18	“Cityview” Patio Stacking Door - Single Glazed	6SpGy	3	0	49%	-3%	6.2	0.28	0.07	1.23
DAR-021-19	“Cityview” Patio Stacking Door - Single Glazed	6EVEvrGn	3.5	2.5	55%	18%	4.7	0.3	0.39	1.23

Window ID	System	Glazing	Cooling Stars	Heating Stars	Cool %	Heat %	Uw	SHGC	Tvw	Air Inf
DAR-020-01	“Cityview” Patio Sliding Door - Single Glazed	6.38CPNtl	3	3.5	50%	29%	4.4	0.4	0.46	0.48
DAR-020-02	“Cityview” Patio Sliding Door - Single Glazed	6.38CPGn	3.5	3.5	51%	29%	4.3	0.4	0.55	0.48
DAR-020-03	“Cityview” Patio Sliding Door - Single Glazed	6.38CPGy	3.5	3	51%	28%	4.3	0.39	0.3	0.48
DAR-020-04	“Cityview” Patio Sliding Door - Single Glazed	6TS21	4	2	56%	7%	5.4	0.24	0.16	0.48
DAR-020-05	“Cityview” Patio Sliding Door - Single Glazed	6Gy	2.5	2	38%	10%	6.1	0.45	0.32	0.48
DAR-020-06	“Cityview” Patio Sliding Door - Single Glazed	6Clr	1	2.5	22%	19%	6.1	0.65	0.68	0.48
DAR-020-07	“Cityview” Patio Sliding Door - Single Glazed	6EVGy	3.5	3	55%	23%	4.5	0.32	0.25	0.48
DAR-020-08	“Cityview” Patio Sliding Door - Single Glazed	6SolEGy	4	3	58%	21%	4.4	0.28	0.23	0.48
DAR-020-09	“Cityview” Patio Sliding Door - Single Glazed	6SolEClr	3	3.5	49%	29%	4.4	0.41	0.46	0.48
DAR-020-10	“Cityview” Patio Sliding Door - Single Glazed	6.38CPClr	2.5	4	40%	36%	4.3	0.54	0.63	0.48
DAR-020-11	“Cityview” Patio Sliding Door - Single Glazed	6EVClr	2.5	3.5	43%	32%	4.5	0.49	0.51	0.48
DAR-020-12	“Cityview” Patio Sliding Door - Single Glazed	10.38GyLam	2.5	2	39%	13%	5.9	0.46	0.33	0.48
DAR-020-13	“Cityview” Patio Sliding Door - Single Glazed	10.38CPClr	2.5	3.5	43%	35%	4.3	0.51	0.61	0.48
DAR-020-14	“Cityview” Patio Sliding Door - Single Glazed	10.38CPGy	3.5	3	52%	28%	4.3	0.37	0.29	0.48
DAR-020-15	“Cityview” Patio Sliding Door - Single Glazed	10.38CPNtl	3.5	3.5	51%	29%	4.3	0.4	0.48	0.48
DAR-020-16	“Cityview” Patio Sliding Door - Single Glazed	6EVBGn	3.5	3	52%	24%	4.6	0.36	0.44	0.48
DAR-020-17	“Cityview” Patio Sliding Door - Single Glazed	10.38CPGn	3.5	3	54%	26%	4.3	0.35	0.5	0.48
DAR-020-18	“Cityview” Patio Sliding Door - Single Glazed	6AzTS21	4	1.5	57%	6%	5.4	0.23	0.12	0.48
DAR-020-19	“Cityview” Patio Sliding Door - Single Glazed	6EVAB	4	2.5	57%	20%	4.6	0.29	0.3	0.48
DAR-020-20	“Cityview” Patio Sliding Door - Single Glazed	6EVSpGn	4	2.5	56%	20%	4.6	0.3	0.38	0.48
DAR-021-01	“Cityview” Patio Stacking Door - Single Glazed	6.38CPNtl	3	3	47%	24%	4.8	0.41	0.46	1.23
DAR-021-02	“Cityview” Patio Stacking Door - Single Glazed	6.38CPGn	3	3	48%	24%	4.7	0.41	0.56	1.23
DAR-021-03	“Cityview” Patio Stacking Door - Single Glazed	6.38CPGy	3	3	48%	23%	4.7	0.4	0.31	1.23
DAR-021-04	“Cityview” Patio Stacking Door - Single Glazed	6TS21	3.5	1.5	54%	1%	5.7	0.25	0.16	1.23
DAR-021-05	“Cityview” Patio Stacking Door - Single Glazed	6Gy	2	1.5	36%	4%	6.4	0.46	0.33	1.23
DAR-021-06	“Cityview” Patio Stacking Door - Single Glazed	6Clr	1	2	19%	14%	6.4	0.66	0.7	1.23
DAR-021-07	“Cityview” Patio Stacking Door - Single Glazed	6EVGy	3.5	2.5	52%	18%	4.9	0.33	0.25	1.23
DAR-021-08	“Cityview” Patio Stacking Door - Single Glazed	6SolEGy	3.5	2.5	55%	16%	4.8	0.29	0.24	1.23
DAR-021-09	“Cityview” Patio Stacking Door - Single Glazed	6SolEClr	3	3	47%	24%	4.8	0.42	0.47	1.23
DAR-021-10	“Cityview” Patio Stacking Door - Single Glazed	6.38CPClr	2	3.5	38%	31%	4.7	0.55	0.65	1.23
DAR-021-11	“Cityview” Patio Stacking Door - Single Glazed	6EVClr	2.5	3	41%	27%	4.9	0.5	0.53	1.23
DAR-021-12	“Cityview” Patio Stacking Door - Single Glazed	10.38GyLam	2	2	36%	8%	6.2	0.47	0.33	1.23
DAR-021-13	“Cityview” Patio Stacking Door - Single Glazed	10.38CPNtl	3	3	50%	27%	4.5	0.4	0.49	1.23
DAR-021-14	“Cityview” Patio Stacking Door - Single Glazed	10.38CPGy	3.5	3	51%	26%	4.5	0.38	0.3	1.23
DAR-021-15	“Cityview” Patio Stacking Door - Single Glazed	10.38CPClr	2.5	3.5	42%	33%	4.5	0.51	0.63	1.23
DAR-021-16	“Cityview” Patio Stacking Door - Single Glazed	10.38CPGn	3.5	3	53%	24%	4.5	0.35	0.51	1.23
DAR-021-17	“Cityview” Patio Stacking Door - Single Glazed	6AzTS21	4	1.5	56%	3%	5.5	0.23	0.12	1.23
DAR-021-18	“Cityview” Patio Stacking Door - Single Glazed	6SpGy	3	0	49%	-3%	6.2	0.28	0.07	1.23
DAR-021-19	“Cityview” Patio Stacking Door - Single Glazed	6EVEvrGn	3.5	2.5	55%	18%	4.7	0.3	0.39	1.23
