The Darley 45mm door is an ideal choice for modern architectural requirements. This system is ideal suited for shopping centres, showrooms and commercial buildings.
It is also compatible with Darley’s other commercial window & door systems and comes with a range of heavy duty mullion options for tall framing and high wind areas. As with all of Darley’s commercial door systems, it is available in powder coat and clear anodised finishes
The Window Energy Rating Scheme (WERS) is accredited by the AFRC – which means that WERS ratings are compliant with the NCC.
Reports are prescribed both the window performance for total window U Value (Uw) and total window Solar Heat Gain Coefficient (SHGCw).
U-value measures how well a product prevents heat from escaping.
It is a measure of the rate of non-solar heat loss or gain through a material or assembly.
U-value ratings generally fall between 2.0-10.0 W/m2.K for Australian products. The lower the U-value, the greater a window’s resistance to heat and cold flow and the better its insulating value.
SHGC measures how well a product blocks heat caused by sunlight. SHGC is expressed as a number between 0 and 1. The lower a window’s SHGC, the less solar heat it transmits.
Under the Building Code of Australia, we are required to produce windows and doors that meet mandatory minimum specifications under Australian Standard (AS) 2047 – including AS1288.
The Darley 45mm door is an ideal choice for modern architectural requirements. This system is ideal suited for shopping centres, showrooms and commercial buildings.
It is also compatible with Darley’s other commercial window & door systems and comes with a range of heavy duty mullion options for tall framing and high wind areas. As with all of Darley’s commercial door systems, it is available in powder coat and clear anodised finishes
The Window Energy Rating Scheme (WERS) is accredited by the AFRC – which means that WERS ratings are compliant with the NCC.
Reports are prescribed both the window performance for total window U Value (Uw) and total window Solar Heat Gain Coefficient (SHGCw).
U-value measures how well a product prevents heat from escaping.
It is a measure of the rate of non-solar heat loss or gain through a material or assembly.
U-value ratings generally fall between 2.0-10.0 W/m2.K for Australian products. The lower the U-value, the greater a window’s resistance to heat and cold flow and the better its insulating value.
SHGC measures how well a product blocks heat caused by sunlight. SHGC is expressed as a number between 0 and 1. The lower a window’s SHGC, the less solar heat it transmits.
Under the Building Code of Australia, we are required to produce windows and doors that meet mandatory minimum specifications under Australian Standard (AS) 2047 – including AS1288.
| System | Maximum weight | Maximum hieight | Maxiumim Width | Glass Thickness | Test Report No. | Water Rating (Pa) | Structural (Pa) | Ultimate (Pa) |
|---|---|---|---|---|---|---|---|---|
| 45mm water rated door (hinged inward) | N/A | N/A | M/A | 6mm to 28mm | 0569.18 | 200 | 1500 | 3000 |
| 45mm water rated door (hinged outward) | N/A | N/A | N/A | 6mm to 28mm | 0549.18 | 300 | 1500 | 3000 |
