About KlassicView 76mm Double Hung Window

The KlassicView 76mm Double Hung Window incorporates the features and functionality of the 53mm KlassicView double hung window into a commercial grade version.

With a sash weight of up to 21kgs per panel, the 76mm double hung window can be coupled with the full range of KlassicView windows and doors by installing a variety of adaptors.
Designed and engineered in Australia for Australian climatic conditions, it is available in a range of standard configurations.

The entire KlassicView range has been tested and exceeds Australian Standard AS2047.

Double Hung Design Features:

Accepts glass thickness from 4mm to 10.38mm single glazed glass and 16 & 20mm double glazed glass
Sash width up to 1200mm
Sash weight up to 21Kgs per panel
Slide in flyscreens with no need of any clips

Flyscreen grove on top and bottom of window
Can be coupled to the full KlassicView ragne of window and doors with the use of a variety of adaptors
Plus can be attached to the Fixed window system to have lowlights or highlights or side lights

WERS Ratings

The Window Energy Rating Scheme (WERS) is accredited by the AFRC – which means that WERS ratings are compliant with the NCC.

Reports are prescribed both the window performance for total window U Value (Uw) and total window Solar Heat Gain Coefficient (SHGCw).

U-value

U-value measures how well a product prevents heat from escaping.

It is a measure of the rate of non-solar heat loss or gain through a material or assembly.

U-value ratings generally fall between 2.0-10.0 W/m2.K for Australian products. The lower the U-value, the greater a window’s resistance to heat and cold flow and the better its insulating value.

Solar Heat Gain Co-efficient (SHGC)

SHGC measures how well a product blocks heat caused by sunlight. SHGC is expressed as a number between 0 and 1. The lower a window’s SHGC, the less solar heat it transmits.

Tested to AS2047

Under the Building Code of Australia, we are required to produce windows and doors that meet mandatory minimum specifications under Australian Standard (AS) 2047 – including AS1288.

Simulations of High Winds and Driving Rains

AS4420.2 Deflection Test – positive and negative wind pressures are applied to the face of the window to test the maximum deflection under wind load.
AS4420.5 Water Penetration Resistance Test – to verify that no water leaks through the window into the building.

Operating Force Requirement

AS4420.3 Operating Force Test – to verify that an opening sash is capable of opening and closing without undue effort.

Air Infiltration Pressure

AS4220.4 Air In filtration Test – the air leakage of a window is tested to ensure energy and acoustic efficiency.

Ultimate Strength Testing

AS4420.6 Ultimate Strength Test – negative and positive wind pressures are applied to the window to at least 1.5 times the design wind pressure to ensure it does not fail in unusual wind conditions.

Download CAD Drawings

Please note: file will be in .zip format.

About

About KlassicView 76mm Double Hung Window

The KlassicView 76mm Double Hung Window incorporates the features and functionality of the 53mm KlassicView double hung window into a commercial grade version.

With a sash weight of up to 21kgs per panel, the 76mm double hung window can be coupled with the full range of KlassicView windows and doors by installing a variety of adaptors.
Designed and engineered in Australia for Australian climatic conditions, it is available in a range of standard configurations.

The entire KlassicView range has been tested and exceeds Australian Standard AS2047.

Double Hung Design Features:

Accepts glass thickness from 4mm to 10.38mm single glazed glass and 16 & 20mm double glazed glass
Sash width up to 1200mm
Sash weight up to 21Kgs per panel
Slide in flyscreens with no need of any clips

Flyscreen grove on top and bottom of window
Can be coupled to the full KlassicView ragne of window and doors with the use of a variety of adaptors
Plus can be attached to the Fixed window system to have lowlights or highlights or side lights

Wers Ratings

WERS Ratings

The Window Energy Rating Scheme (WERS) is accredited by the AFRC – which means that WERS ratings are compliant with the NCC.

Reports are prescribed both the window performance for total window U Value (Uw) and total window Solar Heat Gain Coefficient (SHGCw).

U-value

U-value measures how well a product prevents heat from escaping.

It is a measure of the rate of non-solar heat loss or gain through a material or assembly.

U-value ratings generally fall between 2.0-10.0 W/m2.K for Australian products. The lower the U-value, the greater a window’s resistance to heat and cold flow and the better its insulating value.

Solar Heat Gain Co-efficient (SHGC)

SHGC measures how well a product blocks heat caused by sunlight. SHGC is expressed as a number between 0 and 1. The lower a window’s SHGC, the less solar heat it transmits.

Testing

Tested to AS2047

Under the Building Code of Australia, we are required to produce windows and doors that meet mandatory minimum specifications under Australian Standard (AS) 2047 – including AS1288.

Simulations of High Winds and Driving Rains

AS4420.2 Deflection Test – positive and negative wind pressures are applied to the face of the window to test the maximum deflection under wind load.
AS4420.5 Water Penetration Resistance Test – to verify that no water leaks through the window into the building.

Operating Force Requirement

AS4420.3 Operating Force Test – to verify that an opening sash is capable of opening and closing without undue effort.

Air Infiltration Pressure

AS4220.4 Air In filtration Test – the air leakage of a window is tested to ensure energy and acoustic efficiency.

Ultimate Strength Testing

AS4420.6 Ultimate Strength Test – negative and positive wind pressures are applied to the window to at least 1.5 times the design wind pressure to ensure it does not fail in unusual wind conditions.

Technical Manuals

CAD Drawings

Download CAD Drawings

Please note: file will be in .zip format.

Download Brochure

Specifications

System	Maximum weight per panel	Maximum height per panel	Maxiumim Width per panel	Glass Thickness	Test Report No.	Water Rating (Pa)	Structural (Pa)	Ultimate (Pa)
Klassicview 76mm Double Hung Window	20kgs	2400mm	1200mm	singale glazed=10.38mm	AZT0148.13	250	1800	2800
				double glazed=20mm

Residential Hardware

Find Out More

Window ID	System	Glazing	Cooling Stars	Heating Stars	Cool %	Heat %	Uw	SHGC	Tvw	Air Inf
DAR-035-01	Klassic View 76mm Double Hung - Single Glazed	10.38CPClr	2.5	3	40%	28%	4.7	0.51	0.62	4.01
DAR-035-02	Klassic View 76mm Double Hung - Single Glazed	6.38CPClr	2	3	37%	28%	4.7	0.55	0.64	4.01
DAR-035-03	Klassic View 76mm Double Hung - Single Glazed	10.38CPGy	3	2.5	50%	20%	4.7	0.38	0.3	4.01
DAR-035-04	Klassic View 76mm Double Hung - Single Glazed	10.38ClrLam	1.5	2	26%	11%	6.2	0.59	0.67	4.01
DAR-035-05	Klassic View 76mm Double Hung - Single Glazed	10.38GyLam	2	1.5	36%	5%	6.2	0.47	0.32	4.01
DAR-035-06	Klassic View 76mm Double Hung - Single Glazed	10.38EVGy	3.5	2.5	53%	15%	4.8	0.32	0.24	4.01
DAR-035-07	Klassic View 76mm Double Hung - Single Glazed	10.38EVSpGn	3.5	2.5	54%	16%	4.7	0.32	0.46	4.01
DAR-035-08	Klassic View 76mm Double Hung - Single Glazed	10.38VLamSpGn	2.5	1.5	40%	2%	6.2	0.41	0.51	4.01
DAR-035-09	Klassic View 76mm Double Hung - Single Glazed	6.38ClrLam	1	2	21%	12%	6.3	0.65	0.7	4.01
DAR-035-10	Klassic View 76mm Double Hung - Single Glazed	6.38CPGy	3	2.5	48%	21%	4.7	0.4	0.3	4.01
DAR-035-11	Klassic View 76mm Double Hung - Single Glazed	6.38CPNtl	3	2.5	47%	21%	4.8	0.41	0.46	4.01
DAR-035-12	Klassic View 76mm Double Hung - Single Glazed	6.38CPGn	3	2.5	48%	21%	4.7	0.41	0.56	4.01
DAR-035-13	Klassic View 76mm Double Hung - Single Glazed	6.38TransLam	3	0	45%	-5%	6.3	0.33	0.26	4.01
DAR-035-14	Klassic View 76mm Double Hung - Single Glazed	6.38GyLam	2	1.5	34%	4%	6.3	0.49	0.33	4.01
DAR-035-15	Klassic View 76mm Double Hung - Single Glazed	6EVGy	3.5	2.5	52%	15%	4.9	0.33	0.25	4.01
DAR-035-16	Klassic View 76mm Double Hung - Single Glazed	6AzTS21	3.5	0	54%	-2%	5.7	0.24	0.12	4.01
DAR-035-17	Klassic View 76mm Double Hung - Single Glazed	6EVBlGn	3	2.5	49%	17%	4.9	0.37	0.44	4.01
DAR-035-18	Klassic View 76mm Double Hung - Single Glazed	6EVSpGn	3.5	2	54%	12%	4.9	0.3	0.38	4.01
DAR-035-19	Klassic View 76mm Double Hung - Single Glazed	6EVClr	2.5	3	40%	24%	4.9	0.51	0.53	4.01
DAR-035-20	Klassic View 76mm Double Hung - Single Glazed	6ET	2	3.5	36%	29%	4.7	0.56	0.64	4.01
DAR-035-21	Klassic View 76mm Double Hung - Single Glazed	6.38SnClr	2.5	2.5	42%	20%	5.1	0.47	0.53	4.01
DAR-035-22	Klassic View 76mm Double Hung - Single Glazed	6.38SnGy	3	2	50%	14%	5.1	0.35	0.25	4.01
DAR-035-23	Klassic View 76mm Double Hung - Single Glazed	6SnClr	2.5	2.5	41%	20%	5.1	0.48	0.53	4.01
DAR-035-24	Klassic View 76mm Double Hung - Single Glazed	5Clr	1	2	19%	11%	6.4	0.66	0.69	4.01
DAR-035-25	Klassic View 76mm Double Hung - Single Glazed	5Gy	2	1.5	33%	3%	6.4	0.49	0.37	4.01
DAR-035-26	Klassic View 76mm Double Hung - Single Glazed	5SpGy	3	0	46%	-7%	6.4	0.31	0.1	4.01
DAR-035-27	Klassic View 76mm Double Hung - Single Glazed	4Clr	1	2	17%	12%	6.4	0.68	0.7	4.01
DAR-035-28	Klassic View 76mm Double Hung - Single Glazed	4Gy	1.5	1.5	30%	5%	6.4	0.53	0.43	4.01
DAR-035-29	Klassic View 76mm Double Hung - Single Glazed	4SnClr	2.5	2.5	40%	20%	5.2	0.49	0.53	4.01
DAR-036-01	Klassic View 76mm Double Hung - Double Glazed	6.38CPGy/6/4Clr	3.5	3	55%	28%	3.9	0.36	0.27	4.01
DAR-036-02	Klassic View 76mm Double Hung - Double Glazed	6.38CP/6/4Clr	3.5	3.5	54%	28%	3.9	0.37	0.41	4.01
DAR-036-03	Klassic View 76mm Double Hung - Double Glazed	6.38CPClr/6/4Clr	3	4	45%	35%	3.9	0.49	0.58	4.01
DAR-036-04	Klassic View 76mm Double Hung - Double Glazed	6TS21/6/4Clr	4.5	2	64%	14%	4.2	0.2	0.15	4.01
DAR-036-05	Klassic View 76mm Double Hung - Double Glazed	6TS21/6/4ET	5	2.5	67%	16%	3.9	0.18	0.14	4.01
DAR-036-06	Klassic View 76mm Double Hung - Double Glazed	6EVGy/6/4Clr	4	3	59%	23%	4	0.29	0.23	4.01
DAR-036-07	Klassic View 76mm Double Hung - Double Glazed	6SGrn/6/4Clr	3.5	3	54%	22%	4.4	0.34	0.47	4.01
DAR-036-08	Klassic View 76mm Double Hung - Double Glazed	5Clr/6/5Clr	2	3.5	37%	34%	4.4	0.57	0.62	4.01
DAR-036-09	Klassic View 76mm Double Hung - Double Glazed	4Sn/8/4Clr	3.5	3.5	50%	33%	3.9	0.43	0.48	4.01
DAR-036-10	Klassic View 76mm Double Hung - Double Glazed	4SpGn/8/4ET	4	3.5	57%	29%	3.7	0.34	0.48	4.01
DAR-036-11	Klassic View 76mm Double Hung - Double Glazed	4Clr/8/4Clr	2	4	35%	37%	4.2	0.6	0.63	4.01
DAR-036-12	Klassic View 76mm Double Hung - Double Glazed	4Clr/8/4ET	2.5	4	41%	41%	3.7	0.56	0.58	4.01
DAR-036-13	Klassic View 76mm Double Hung - Double Glazed	4FGI Mat/ 8Ar / 6FGI OE Prv	3	4.5	48%	43%	3.3	0.5	0.63	4.01
DAR-036-14	Klassic View 76mm Double Hung - Double Glazed	4FGI Env Clr / 8Ar / 4FGI OE Clr	3	4.5	49%	42%	3.3	0.49	0.63	4.01
DAR-036-15	Klassic View 76mm Double Hung - Double Glazed	4FGI Env Gy / 8Ar / 4FGI OE Gy	4	3.5	59%	34%	3.3	0.35	0.39	4.01

Window ID	System	Glazing	Cooling Stars	Heating Stars	Cool %	Heat %	Uw	SHGC	Tvw	Air Inf
DAR-035-01	Klassic View 76mm Double Hung - Single Glazed	10.38CPClr	2.5	3	40%	28%	4.7	0.51	0.62	4.01
DAR-035-02	Klassic View 76mm Double Hung - Single Glazed	6.38CPClr	2	3	37%	28%	4.7	0.55	0.64	4.01
DAR-035-03	Klassic View 76mm Double Hung - Single Glazed	10.38CPGy	3	2.5	50%	20%	4.7	0.38	0.3	4.01
DAR-035-04	Klassic View 76mm Double Hung - Single Glazed	10.38ClrLam	1.5	2	26%	11%	6.2	0.59	0.67	4.01
DAR-035-05	Klassic View 76mm Double Hung - Single Glazed	10.38GyLam	2	1.5	36%	5%	6.2	0.47	0.32	4.01
DAR-035-06	Klassic View 76mm Double Hung - Single Glazed	10.38EVGy	3.5	2.5	53%	15%	4.8	0.32	0.24	4.01
DAR-035-07	Klassic View 76mm Double Hung - Single Glazed	10.38EVSpGn	3.5	2.5	54%	16%	4.7	0.32	0.46	4.01
DAR-035-08	Klassic View 76mm Double Hung - Single Glazed	10.38VLamSpGn	2.5	1.5	40%	2%	6.2	0.41	0.51	4.01
DAR-035-09	Klassic View 76mm Double Hung - Single Glazed	6.38ClrLam	1	2	21%	12%	6.3	0.65	0.7	4.01
DAR-035-10	Klassic View 76mm Double Hung - Single Glazed	6.38CPGy	3	2.5	48%	21%	4.7	0.4	0.3	4.01
DAR-035-11	Klassic View 76mm Double Hung - Single Glazed	6.38CPNtl	3	2.5	47%	21%	4.8	0.41	0.46	4.01
DAR-035-12	Klassic View 76mm Double Hung - Single Glazed	6.38CPGn	3	2.5	48%	21%	4.7	0.41	0.56	4.01
DAR-035-13	Klassic View 76mm Double Hung - Single Glazed	6.38TransLam	3	0	45%	-5%	6.3	0.33	0.26	4.01
DAR-035-14	Klassic View 76mm Double Hung - Single Glazed	6.38GyLam	2	1.5	34%	4%	6.3	0.49	0.33	4.01
DAR-035-15	Klassic View 76mm Double Hung - Single Glazed	6EVGy	3.5	2.5	52%	15%	4.9	0.33	0.25	4.01
DAR-035-16	Klassic View 76mm Double Hung - Single Glazed	6AzTS21	3.5	0	54%	-2%	5.7	0.24	0.12	4.01
DAR-035-17	Klassic View 76mm Double Hung - Single Glazed	6EVBlGn	3	2.5	49%	17%	4.9	0.37	0.44	4.01
DAR-035-18	Klassic View 76mm Double Hung - Single Glazed	6EVSpGn	3.5	2	54%	12%	4.9	0.3	0.38	4.01
DAR-035-19	Klassic View 76mm Double Hung - Single Glazed	6EVClr	2.5	3	40%	24%	4.9	0.51	0.53	4.01
DAR-035-20	Klassic View 76mm Double Hung - Single Glazed	6ET	2	3.5	36%	29%	4.7	0.56	0.64	4.01
DAR-035-21	Klassic View 76mm Double Hung - Single Glazed	6.38SnClr	2.5	2.5	42%	20%	5.1	0.47	0.53	4.01
DAR-035-22	Klassic View 76mm Double Hung - Single Glazed	6.38SnGy	3	2	50%	14%	5.1	0.35	0.25	4.01
DAR-035-23	Klassic View 76mm Double Hung - Single Glazed	6SnClr	2.5	2.5	41%	20%	5.1	0.48	0.53	4.01
DAR-035-24	Klassic View 76mm Double Hung - Single Glazed	5Clr	1	2	19%	11%	6.4	0.66	0.69	4.01
DAR-035-25	Klassic View 76mm Double Hung - Single Glazed	5Gy	2	1.5	33%	3%	6.4	0.49	0.37	4.01
DAR-035-26	Klassic View 76mm Double Hung - Single Glazed	5SpGy	3	0	46%	-7%	6.4	0.31	0.1	4.01
DAR-035-27	Klassic View 76mm Double Hung - Single Glazed	4Clr	1	2	17%	12%	6.4	0.68	0.7	4.01
DAR-035-28	Klassic View 76mm Double Hung - Single Glazed	4Gy	1.5	1.5	30%	5%	6.4	0.53	0.43	4.01
DAR-035-29	Klassic View 76mm Double Hung - Single Glazed	4SnClr	2.5	2.5	40%	20%	5.2	0.49	0.53	4.01
DAR-036-01	Klassic View 76mm Double Hung - Double Glazed	6.38CPGy/6/4Clr	3.5	3	55%	28%	3.9	0.36	0.27	4.01
DAR-036-02	Klassic View 76mm Double Hung - Double Glazed	6.38CP/6/4Clr	3.5	3.5	54%	28%	3.9	0.37	0.41	4.01
DAR-036-03	Klassic View 76mm Double Hung - Double Glazed	6.38CPClr/6/4Clr	3	4	45%	35%	3.9	0.49	0.58	4.01
DAR-036-04	Klassic View 76mm Double Hung - Double Glazed	6TS21/6/4Clr	4.5	2	64%	14%	4.2	0.2	0.15	4.01
DAR-036-05	Klassic View 76mm Double Hung - Double Glazed	6TS21/6/4ET	5	2.5	67%	16%	3.9	0.18	0.14	4.01
DAR-036-06	Klassic View 76mm Double Hung - Double Glazed	6EVGy/6/4Clr	4	3	59%	23%	4	0.29	0.23	4.01
DAR-036-07	Klassic View 76mm Double Hung - Double Glazed	6SGrn/6/4Clr	3.5	3	54%	22%	4.4	0.34	0.47	4.01
DAR-036-08	Klassic View 76mm Double Hung - Double Glazed	5Clr/6/5Clr	2	3.5	37%	34%	4.4	0.57	0.62	4.01
DAR-036-09	Klassic View 76mm Double Hung - Double Glazed	4Sn/8/4Clr	3.5	3.5	50%	33%	3.9	0.43	0.48	4.01
DAR-036-10	Klassic View 76mm Double Hung - Double Glazed	4SpGn/8/4ET	4	3.5	57%	29%	3.7	0.34	0.48	4.01
DAR-036-11	Klassic View 76mm Double Hung - Double Glazed	4Clr/8/4Clr	2	4	35%	37%	4.2	0.6	0.63	4.01
DAR-036-12	Klassic View 76mm Double Hung - Double Glazed	4Clr/8/4ET	2.5	4	41%	41%	3.7	0.56	0.58	4.01
DAR-036-13	Klassic View 76mm Double Hung - Double Glazed	4FGI Mat/ 8Ar / 6FGI OE Prv	3	4.5	48%	43%	3.3	0.5	0.63	4.01
DAR-036-14	Klassic View 76mm Double Hung - Double Glazed	4FGI Env Clr / 8Ar / 4FGI OE Clr	3	4.5	49%	42%	3.3	0.49	0.63	4.01
DAR-036-15	Klassic View 76mm Double Hung - Double Glazed	4FGI Env Gy / 8Ar / 4FGI OE Gy	4	3.5	59%	34%	3.3	0.35	0.39	4.01

Login

About KlassicView 76mm Double Hung Window

Double Hung Design Features:

Residential WERS Rating

WERS Ratings

U-value

Solar Heat Gain Co-efficient (SHGC)

Tested to AS2047

Simulations of High Winds and Driving Rains

Operating Force Requirement

Air Infiltration Pressure

Ultimate Strength Testing

Download CAD Drawings

About KlassicView 76mm Double Hung Window

Double Hung Design Features:

Residential WERS Rating

WERS Ratings

U-value

Solar Heat Gain Co-efficient (SHGC)

Tested to AS2047

Simulations of High Winds and Driving Rains

Operating Force Requirement

Air Infiltration Pressure

Ultimate Strength Testing

Download CAD Drawings

Download Brochure

Specifications

Residential Hardware

Related Products

KlassicView 53mm Double Hung Window

KlassicView 53mm Sliding Window

KlassicView 76mm Awning Window Sections

KlassicView 76mm Fixed Frame

KlassicView 76mm Louvre Window

KlassicView 76mm Sliding Window

KlassicView Hinged Door

KlassicView Sliding Stacking Door

Let’s Start To Connect With Darley Today

Fabricator Enquiry Form

Consumer Enquiry Form

Popular Search Terms

Darley Locations

Darley Aluminium takes great pride in being a valued member of the Australian Glass and Window Association, as we work collaboratively to foster a stronger vision together.

Login
